SpeakerCraft® 5.25" White In-Wall Speaker

SpeakerCraft

Model #:

PROFILE AIM LCR5 THREE

Model #: PROFILE AIM LCR5 THREE
796114
SpeakerCraft
$99,999.00

At a Glance

Product Dimensions 17.13"h x 9"w x 4"d

AIM Series in-ceiling speakers were the first to feature an aimable woofer/tweeter module that aims the sound in any direction you choose. No longer are you bound by the design of your room. Just mount the speakers wherever it’s convenient and point them wherever you want sound.Read More

Available in Store Only

Get to know this product.

Product Overview

Product Overview

AIM Series in-ceiling speakers were the first to feature an aimable woofer/tweeter module that aims the sound in any direction you choose. No longer are you bound by the design of your room. Just mount the speakers wherever it’s convenient and point them wherever you want sound. Profile grilles are available in AIM8, AIM7 and AIM5 models.

Flangeless Appearance

Pivoting Woofer Baffle

Two 5 1/4″ Aluminum/Magnesium Cone Woofers with Phase Plugs

Pivoting 1″ Aluminum/Magnesium Dome Tweeter

Front-Mounted Switches Allow for up to ±3dB of Bass and Treble Adjustment

Useful Documents
Brochure
Installation Guide
Specifications

General Specs

Cut Out Width14.25
Cut Out Height7.5
Frequency Response50Hz – 20kHz
Color Finish NameWhite
RMS Power Handling (Watts)100
ColorWhite
Sensitivity90
Speaker TypeIn-Wall Speakers
Depth (in.)4
Height (in.)17.13
Width (in.)9

General

FamilyProfile AIM LCR
Woofer Size5.25 (Inches)
Woofer ConstructionTwo 5 1/4″ Aluminum/Magnesium Cone Woofers with Phase Plugs
Frequency Response50Hz – 20kHz
Impedance86 (Ohms)
Power Handling100 (Watts)
Sensitivity90 (dB)
TimbreTimbre-Matched to All Three/Four Series Speakers
Dimensions(H x W x D) 17 1/8″ x 9″ x 4″ (235 mm x 443 mm x 102 mm) (with Grille)
Hole Cutout Dimensions(H x W) 7 1/2″ x 14 1/4″ (190 mm x 362 mm)
SwitchesFront-Mounted Switches Allow for up to ±3dB of Bass and Treble Adjustment
WarningProposition 65 Warning for California Residents
